Laser Range Finder ≤55mm×42mm×35mm/≤60g LRF G1535 2S
| Categories | Laser Range Finder |
|---|---|
| Brand | Quanhom Optronics |
| Model | LRF G1535 2S |
| Power Supply | 9V-16V(customizable) |
| Repetition rates | 1-10Hz(adjustable) |
| Operating Temperature | -40℃-+65℃ |
| Update Time | Apr 24,2024 |
- Specification
- download file
- FAQ
- video
- application
Performance |
|||
Continuous ranging frequancy | 1-10Hz (adjustable) | ||
Wavelength | 1535nm±5nm | ||
Laser divergence angle | ≤0.5mrad | ||
Accurate measurement speed | ≥98% | ||
Range accuracy | ≤±2m (RMS) | ||
Ranging resolution | ≤30m | ||
Operating temperature | -40℃～+65℃ | ||
Storage Temperature | -55℃～+70℃ | ||
Product weight | ≤60g | ||
Product size [mm] | ≤55×42×35 | ||
Power supply | 9V-16V | ||
Communication interface | RS422，115200bps | ||
Power consumption | Average power consumption≤1.5W (working at 1Hz), peak power consumption≤5W | ||
|
file name
|
type |
download
|
||
PDF format |
|
|||
For example, there are many different reasons why the lens autofocus is not clear, which can be
1. During the process, above, the moving target of the screen (the lens can be 1/3) focused;
2. The lens has been used for a long time, and the parameters of the drive, CAM and other transmission boards are not clear, and the lens can be adjusted or controlled by the module, and the clarity of the lens;
3. Hardware problems, such as utensils not working, replace the hardware that does not work.
There are many reasons why the lens board and the computer cannot be connected. Please note that you can check them all:
1. Replacing the USB may not interface with the data cable;
2. The replacement of the data cable may be because the data cable is not connected to the computer or the wrong data cable is selected;
3. Confirm the conjecture of the module or the control board, and the possible conjecture is loose;
4. Module or control board hardware problem, replace the hardware.
