LWIR Thermal Camera Module 640 x 512 12μm
The ITZ6412 uncooled infrared module utilizes Vox uncooled LWIR focal plane detectors as its core component, featuring extremely compact dimensions, lighter weight, lower power consumption and ultra-high resolution. It supports customized electrical interfaces for various system integrations. The module can be used in various high-end imaging observation applications, such as small handheld devices, outdoor sighting, lightweight UAVs, security surveillance, automotive night vision, and optoelectronic system integration.
- Compact and lightweight design
- Low power consumption
- Compatibility with different uncooled IR detectors
- Fine image quality and stable working performance
- Embedded infrared image enhancement algorithm
Optical
|
Resolution
|
Spectral Range
|
Pitch Size
|
NETD
|
|
640 X 512
|
8μm~ 12μm
|
12μm
|
≤35mK
|
Mechanical
|
Detector Type
|
Size (L x W x H)
|
Weight
|
|
Uncooled focal plane
|
≤ 41 x41 x28.5 (mm)
|
≤65g
|
Environmental
|
Operating Temp.
|
Storage Temp.
|
|
-40C° ~ +70C°
|
-45C° ~ +85C°
|
Electrical
|
Power Supply
|
Power Consumption
|
|
DC 12V
|
≤1.5W
|
|
Image Frequency
|
Video Output
|
|
25Hz
|
Analog: CVBS Digital: BT656
|
