Manual Focus LWlR Lens 150mm f/1.2
The GLM15012D deliver high-performance thermal imaging across diverse applications. Optimized for the 8-12µm spectral range, it features precise manual focus adjustment for optimal clarity at varying distances. Compatible with uncooled infrared detectors 640x512 resolution, it provides excellent transmission and resolution, making it ideal for thermal cameras, handheld IR devices, security systems, industrial inspection, and R&D applications.
- Interface: thread
- High sensitivity
- Compact, lightweight and durable
- Low refraction and reflection
Specifications
| HFOV | 160x120 | 320x240 | 336x256 | 384x288 | 640x480 | 640x512 |
| 25µm | 1.5 ° | 3.1 ° | 3.2 ° | 3.7 ° | ||
| 17µm | 1.0 ° | 2.1 ° | 2.2 ° | 2.5 ° | 4.2 ° | 4.2 ° |
| 12µm | 0.7 ° | 1.5 ° | 1.5 ° | 1.8 ° | 2.9 ° | 2.9 ° |
Optical
|
Focal Length
|
F/#
|
Average Transmission
|
Wavelength
|
Focus Range
|
|
150mm
|
1.2
|
87%
|
8-12μm
|
6m-Infinity
|
Mechanical
|
Interface
|
Focus Mechanism
|
Dimensions (mm)
|
Weight
|
|
Thread
|
Manual
|
Ø135x196
|
<1100g
|
Environmental
|
Operating Temperature
|
Storage Temperature
|
Front Element Sealing
|
External Coating
|
|
-40°C to +60°C
|
-45°C to +65°C
|
IP67
|
DLC
|
