Continuous Zoom LWIR Lens 15-100mm f/1.1-1.4
The GCZ71514KD features motorized zoom and focus control, enabling rapid, precise remote adjustments for real-time thermal imaging. Operating across the 8-12µm spectral band, the lens provides smooth continuous zoom from wide to narrow fields of view, with integrated autofocus that maintains image clarity during dynamic tracking operations. Designed for PTZ platform integration, it is ideally suited for demanding applications including forest fire monitoring, maritime surveillance, border security, and other long-range infrared observation missions.
- Focus: continuous zoom
- Interface: flange
- High accuracy, smooth zoom and focus performance
- Resistance to shock and vibration
- High optical performance and long lifespan
Specifications
| HFOV | 160x120 | 320x240 | 336x256 | 384x288 | 640x480 | 640x512 | 1024x768 | 1280x1024 |
| 25µm | 2.3°-15.2° | 4.6°-29.9° | 4.8°-31.3° | 5.5°-35.5° | ||||
| 17µm | 1.6°-10.4° | 3.1°-20.6° | 3.3°-21.6° | 3.7°-24.6° | 6.2°-39.9° | 6.2°-39.9° | ||
| 12µm | 1.1°-7.3° | 2.2°-14.6° | 2.3°-15.3° | 2.6°-17.5° | 4.4°-28.7° | 4.4°-28.7° | 7°-44.5° | 8.8°-54.2° |
Optical
|
Focal Length(mm)
|
F/#
|
Wavelength
|
Focus Range
|
|
15-100
|
1.1-1.4
|
8-12μm
|
5m-Infinity /15m-Infinity
|
Mechanical
|
Interface
|
Focus Mechanism
|
Dimensions (mm)
|
Weight
|
|
Flange
|
Motorized
|
Ø106x138mm
|
<1300g
|
Environmental
|
Operating Temperature
|
Storage Temperature
|
Front Infrared Lens Sealing
|
External Coating
|
|
-40°C to +85°C
|
-60°C to +85°C
|
IP67
|
DLC
|
Electrical & Communications
|
Power Input
|
|
DC 12V Average
|
