Mini SDI+CVBS Encoder
The K10 SDI+CVBS Mini Encoder is a professional video encoding product designed for SDI and CVBS signals. It supports asynchronous operation of 1 channel of SDI signal and 1 channel of CVBS signal, dual-stream H.265/H.264 encoded output formats, and audio MP3/AAC formats. The encoding bitrate is adjustable, and the picture quality can be controlled. It supports HTTP/ RTSP/ RTMP/ UDP/ SRT/ RTP/ HLS transmission protocols, ensuring ease of use without any hardware compatibility issues.
- Embedded hardware encoding
- Encoding standards: BASELINE PROFILE / MAIN PROFILE / HIGH PROFILE
- Support intelligent encoding mode for ultra-low latency video transmission with latency as low as 200ms
- Support multi-protocol and multi-stream functions
- Support code stream adding watermark function (OSD), XY axis and the font can be set
- Support for set-top box decoding and low power consumption design
Video
|
Input resolution
|
Encoding standard
|
Encoding level
|
Encoded size
|
Video bitrate
|
Video frame rate
|
OSD
|
|
1920x1080p/1280x720p/720*576i/640*480i or other resolutions
|
H.265 / H.264
|
H.265 MAIN PROFILE， H.264 BASELINE PROFILEH.264 MAIN PROFILE， H.264 HIGH PROFILE
|
320*180~1920*1080 (customizable)
|
CBR/VBR bit rate control 16KBIT/S~20MBIT/S
|
5~60 Hz
|
Text, image
|
Audio
|
Input selection
|
Audio encoding
|
Audio bitrate
|
Sampling rate
|
|
1 channel audio and video interface (support audio gain)
|
AAC/MP3
|
24Kb/s~320Kb/s
|
Default
|
System
|
Network protocol
|
Configuration management
|
|
Support HTTP, RTSP, RTMP, UDP, RTP, multicast, unicast, HLS, ONVIF protocol, GB28181 protocol, FTP
|
Support IE configuration, remote upgrade
|
General
|
Power Supply
|
Power consumption
|
Size
|
Operating Temperature
|
Operating humidity
|
Weight
|
|
12V~2A
|
4W
|
67mm×50mm×20mm(L×W×H)
|
-20°C to +60°C
|
<90%,no condensation
|
38g
|
