Eyepiece Focal Length 30mm Magnifications = 8.3X
The Eyepiece GEC30 is specifically designed for OLED displays, featuring a soft eyecup for comfortable extended viewing. It provides magnification to clearly enlarge images from micro OLED displays. Constructed with high-transmittance optical glass and an aluminum alloy housing, it delivers strong environmental adaptability, making it an ideal optical magnification solution for night vision devices, handheld thermal imaging devices and helmet-mounted display systems.
- Wide selection of magnification and adapted to OLED size
- Lightweight aluminum alloy CNC precision machined oxidation design
- Customized design and manufacturing
Collimator Technical Specifications
|
Focal Length
|
Magnification
|
Eye Relief
|
Pupil Diameter
|
OLED Size
|
Diopter
|
Weight
|
|
30mm
|
8.3X
|
10mm
|
20mm
|
≤0.4"x 60%
|
+/-4 SD
|
<78g
|
Eyepiece Technical Specifications
|
Focal Length
|
Magnification
|
Eye Relief
|
Pupil Diameter
|
OLED Size
|
Diopter
|
Weight
|
|
30mm
|
8.3X
|
30mm
|
8mm
|
≤0.4"
|
+/-4 SD
|
<78g
|
