TIRM Series Thermal Imaging Riflescope
QUANHOM QUANHOM QUANHOM QUANHOM QUANHOM
The TIRM25-3817/35-3817/50-3817 thermal imaging riflescope is an advanced optical targeting device based on infrared thermal radiation detection technology. Capable of delivering clear imaging in total darkness, smoke, haze, or dense foliage, it enables users to accurately detect and lock onto targets. Its core advantage lies in its ability to operate without relying on visible light, instead generating images by detecting infrared heat signatures emitted by objects. This makes it ideal for applications such as night hunting, target detection, security surveillance.
  • All-weather operation
  • High sensitivity thermal module
  • Advanced image processing
  • Rugged & ergonomic design
Specifications

TIRM Series Parameters

Detector model

TIRM25-3817

TIRM35-3817

TIRM50-3817

Resolution

384x288

Image Sensor

Uncooled Focal Plane

Response waveband

8-14   μm

Pixel Pitch

17um

Focal   Length

25   mm

35   mm

50   mm

F#

1.0

1.0

1.1

FOV

14.9° x 11.2°

10.7° x 8.0°

7.5° x 5.6°

Optical   Magnification

2X

2.8X

4X

OLED

800 x 600 /9.7μm OLED

Pupil Diameter

35mm

Reticle Style

22mm

Reticle Color

10mm

Battery Operating Time

8 h (@ 25 °C)

Auto Standby Mode

×

Work Temperature

-20 °C to +60 °C ( -40 °C to +60 °C, with low   temperature battery]

Eyepiece Optional

Eye Relief 50mm, Magnification   15X

  Eye Relief 35mm, Magnification   17.5X
