- All-weather operation
- High sensitivity thermal module
- Advanced image processing
- Rugged & ergonomic design
Thermal imaging parameters | ||
Detector model | TIRH35-3812 | TIRH50-6412 |
Resolution | 384x288 | 640x512 |
Image Sensor | Uncooled Focal Plane Arrays | |
Response waveband | 8-14 μm | |
Frame rate | 50Hz | |
NETD | ≤35mk(@f1.0, 25℃) | |
Pixel Pitch | 12um | |
Focal Length | 35 mm | 50 mm |
Detection distance | 1800m/2600m | |
IFOV | 0.343 mrad | 0.24 mrad |
Field of View | 7.5° × 5.7° | 8.78° × 7.03° |
Min. Focusing Distance | 3.5m | 5m |
Aperture | F1.0 | |
Magnification | 3.0x | 2.6x |
| Image display | ||
Display | 1024x768, 0.39 inch, OLED | |
Palettes | Black hot, white hot, red hot, fusion | |
Exit Pupil | 6mm | |
Eye Relief | 45mm | |
Diopter range | -5 D to 3 D | |
| System functionality | ||
Record Video | On-board video recording | |
Capture Snapshot | Yes | |
Standby Mode | Yes | |
Non-uniform Correction | Auto, External Correction | |
Storage capacity | Built-in EMMC (64 GB) | |
The picture within the picture | Yes | |
Bad spot correction | Yes | |
Hot spot | Yes | |
Hot spot tracking | Yes | |
Electron zoom | 1X, 2X, 4X, 8X | |
Cross display | Yes | |
Ranging function | NO | |
| Power supply | ||
Battery Type | Replaceable Applicable type: CR123A, RCR123A | |
Battery Operating Time | 7 h (25 °C, with hotspot off) | 6.5 h (25 °C, with hotspot off) |
Battery Capacity Display | Yes | |
Anti-reverse Battery Connection | Yes | |
Overvoltage Protection | Yes | |
Type-C Power | 5 VDC, 2 A Supports external power supply | |
| Common parameter | ||
Work Temperature/Humidity | -20 °C to 55 °C (-4 °F to 131°F) | |
Protection Level | IP67 | |
Vibration & Shock | 750 g/1 ms | |
Dimension | 205×68×63mm | 220×76×69mm |
Weight | 537 g without eyepiece and batteries | 588 g without eyepiece and batteries |
Interface | Type-C | |
