TIRC Series Thermal Imaging Riflescope Clipon
QUANHOM QUANHOM QUANHOM QUANHOM QUANHOM
The TIRC35-3812/50-6412 thermal imaging riflescope is an advanced optical targeting device based on infrared thermal radiation detection technology. Capable of delivering clear imaging in total darkness, smoke, haze, or dense foliage, it enables users to accurately detect and lock onto targets. Its core advantage lies in its ability to operate without relying on visible light, instead generating images by detecting infrared heat signatures emitted by objects. This makes it ideal for applications such as night hunting, target detection, security surveillance.
  • All-weather operation
  • High sensitivity thermal module
  • Advanced image processing
  • Rugged & ergonomic design
Specifications

Thermal   imaging parameters

Detector model

TIRC35-3812

TIRC50-6412

Resolution

384x288

640x512

Image   Sensor

Uncooled   Focal Plane Arrays

Response waveband

8-14   μm

Frame rate

50Hz

NETD

≤35mk(@f1.0, 25℃)

Pixel Pitch

12um

Focal   Length

35   mm

50   mm

Detection   Distance

1800m/2600m

IFOV

0.343 mrad

0.24 mrad

Field   of View

7.5° ×   5.7°

8.78° ×   7.03°

Min. Focusing Distance

3.5m

5m

Aperture

F1.0

Magnification

1x


Image display

Display

1024x768, 0.39 inch, OLED

Palettes

Black hot,   white hot, red hot, fusion

Exit Pupil

22mm

Eye Relief

10mm


System functionality

Record   Video

On-board   video recording

Capture Snapshot

Yes

Standby   Mode

Yes

Non-uniform Correction

Auto, External Correction

Storage   capacity

Built-in   EMMC (64 GB)

The picture within the picture

Yes

Bad spot   correction

Yes

Hot spot

Yes

Hot spot   tracking

Yes

Cross display

Yes

Ranging   function

NO


Power supply

Battery   Type

Replaceable

Applicable   type: CR123A, RCR123A

Battery Operating Time

7 h (25 °C, with hotspot off)

6.5 h (25 °C, with hotspot off)

Battery   Capacity Display

Yes

Anti-reverse Battery Connection

Yes

Overvoltage   Protection

Yes

Type-C Power

5 VDC, 2 A

Supports external power supply


Common  parameter

Work Temperature/Humidity

-20 °C to 55 °C (-4 °F to 131°F)

Protection   Level

IP67

Vibration & Shock

750 g/1 ms

Dimension

179×68×63mm

192×76×69mm

Weight

532 g without eyepiece and batteries

583 g without eyepiece and batteries

Interface

Type-C
