Image Sensor

VOx Uncooled   Focal Plane Arrays

Max.   Resolution

384 × 288

Pixel   Interval

17 μm

Response   Waveband

8 μm to 14 μm

NETD

<35 mK (@25°C), F# = 1.0

MRTD

500mK

Lens (Focal   Length)

25 mm

Magnification

1.7-13.6

Field of View

14.88° × 11.19°

Aperture

F1.0

Frame   Frequency

50 Hz

Monitor

0.39 inch,   OLED, 1024 × 768

Palettes

Black Hot, White Hot, Red Hot,   Fusion

FFC (Flat   Field Correction) Mode

Auto, Manual,   External Correction

Digital Zoom

1 ×, 2 ×, 4 ×, 8 ×

Hot Track

Yes

Detection   Range

882 m

Storage

Built-in memory module (16 GB)

Wi-Fi

Yes

Capture   Snapshot

Yes

Record Video

Yes

Standby Mode

Yes

Hardware Interface

Type-C USB

Power

5 VDC/2 A

Power Consumption

1.5 W

Operating   Temperature

From -30°C to 55°C (-22°F to 131°F); Humidity: 90% or   Less

Protection   Level

IP67

Vibration   & Shock

MIL-STD-810F

Drop Test Height

2 m (6.56 feet)

Weight

<330g

Dimensions   [mm]

189mm x73.3mm x 66mm (7.44" × 2.90" ×   2.60")
