- All-weather operation
- High sensitivity thermal module
- Advanced image processing
- Rugged & ergonomic design
Thermal Module | |||||
Model | TIRH097XG-2512 | TIRH15XG-2512 | TIRH15XG-3812 | TIRH19XG-3812 | TIRH25XG-3812 |
Image Sensor | VOx Uncooled Focal Plane Arrays | ||||
Max. Resolution | 256 x 192 | 384 × 288 | |||
Pixel Interval | 12 μm | ||||
Response Waveband | 8 μm to 14 μm | ||||
NETD | <35 mK (@25°C, F# = 1.0) | ||||
MRTD | 500mK | ||||
Lens (Focal Length) | 9.7 mm | 15 mm | 19mm | 25 mm | |
Detection Range | 458m | 708m | 897m | 1180m | |
Field of View | 18.00° × 13.55° | 11.69° × 8.78° | 17.5° × 13.1° | 13.8° × 10.4° | 10.5° × 7.9° |
Aperture | F1.0 | ||||
Frame Frequency | 25 Hz | 50 Hz | |||
| Image Display | |||||
Display resolution | 720 x 540 | 1280 x 960 | |||
Display | LCOS | ||||
Palettes | Black Hot, White Hot, Red Hot, Fusion | ||||
Brightness adjustment | 1~5 gears are adjustable | ||||
Digital Zoom | 1 ×, 2 ×, 4 ×, 8 × | ||||
Magnification | 1 - 8 | 1.42 - 11.36 | 1.47 - 11.76 | 1.86 - 14.88 | 2.45 - 19.6 |
Contrast adjustment | 1~5 gears are adjustable | ||||
| Smart Function | |||||
Visual adjustment | Yes | ||||
Wi-Fi | Yes | ||||
Interface | TYPE-C | ||||
Capture Snapshot | Yes | ||||
Record Video | Yes | ||||
Anti-burn | Yes | ||||
| System | |||||
Storage | Built-in EMMC v5.1 Interface high-speed storage (8 GB) | ||||
Operating Temperature | - 20~55 ℃ | ||||
Protection Level | IP67 | ||||
Weight | <330g | ||||
Dimensions [mm] | ≤57mm x 57.7mm x 158.9mm | ≤57mm x 57.7mm x 171mm | |||
